Vivotek AE-238 - Page 13

13
English
7.
If using the AM-21E wall-mount bracket, secure the intersection bracket to the bottom
of the housing by driving two screws.
AM-11F
AM-811
AM-21D
AM-21E
Below are the mounting hole dimensions for the mounting brackets. Chances are you may
need to plan for the locations of the brackets.
