14
If using other mount brackets, use the included M6 screws to secure the housing to the
bracket. Use the mounting holes indicated below.
x2
thread
Safety
tether wire
8.
Install the housing to the wall-mount bracket by aiming and pressing the spring mortise,
and hook the bracket onto the groove in the spring mortise.
Secure the T30 anti-tamper screws
on the other side using the included
L-wrench.
Connect the included safety wire
between enclosure and bracket.
