English
Use the included M10 hex socket screws to secure the power box to a pole-mount or corner mount
bracket.
M10
3/4” conduit
AM-314
AM-315
AM-414
AM-21D
AM-21E
Box:
AA-351
AA-352
AM-718
Outdoor PoE switch:
AW-GEU-083A-240
AW-GET-083A-120
AW-GET-123A-240
AW-GEU-086A-240
AW-GET-086A-120
AW-GET-126A-240
Speed Dome:
SD9361/62/63/64/65/66
SD83xx
AM-212/221/220/21C
The mounting hole denition is illustrated below. The same mounting hole pattern apply to all pole-
mount and corner-mount brackets.
