18
AM-21D
AM-21E
If a power box or outdoor PoE switch is applied, Use the following mounting positions for the camera
housings (via AM-21D and AM-21E).
10.
If an IR illuminator is preferred, remove the metal cover from underneath the housing.
Install the IR unit (AI-106, -107, -108, -109) by fastening 4 T30 anti-tamper screws. Note
that the bubber gasket should be in place when you install the unit.
