Refer to the table below for the description of the included screws:
Screw Description No. of
screws
Material char.
M5X10 (A) 4
M4X12 (B) 3
M3X6 (C/E/F/K) 3
M3X8 (D/L/J) 3
M3X6 (H) 2
M3X8 (I) 4
Hex wrench and hex
socket screw
1
NOTE:
1. Route cables before you secure the accessories to a wall.
2. For details on the cable connections with each camera, please refer to their Quick
Installation Guide.
For cabling and conguration details with each network camera, please refer to their
documentation.
