Technical Specications
Technical Specications
Model CC8371-HV
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128MB
RAM 256MB
Camera Features
Image Sensor 1/2.8" Progressive CMOS
Maximum Resolution 2048x1536 (3MP)
Lens Type Fixed-focal
Focal Length f = 1.45 mm
Aperture F2.2
Field of View
180° (horizontal)
120° (vertical)
180° (diagonal)
Shutter Time 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Pro
Day/Night
Removable IR-cut lter for day & night
function
Minimum Illumination
<0.07 Lux @ F2.2 (Color)
<0.001 Lux @ F2.2 (B/W)
Tilt Range ±25°
Pan/Tilt/Zoom
Functionalities
ePTZ: 48x digital zoom (4x on IE plug-in, 12x
built-in)
IR Illuminators
Built-in IR illuminators, effective up to 15
meters with Smart IR
On-board Storage
Slot type: MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
Compression H.264 & MJPEG
Maximum Frame Rate 30 fps @ 2048x1536
Maximum Streams 3 simultaneous streams
S/N Ratio 59. 2 dB
Dynamic Range 100 dB
Video Streaming
Adjustable resolution, quality and bitrate;
Smart Stream II
Image Settings
Time stamp, text overlay, ip & mirror,
scheduled prole settings, congurable
brightness/contrast/saturation/sharpness,
pixel calculator, 3D-Noise reduction, white
balance, exposure control, gain, backlight
compensation, privacy masks
Audio
Audio Capability One-way Audio
Compression G.711, G.726
Interface Built-in Microphone
Effective Range 5 meters
Network
Users Live viewing for up to 10 clients
Protocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/
RTP/RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS,
DDNS, PPPoE, CoS, QoS, SNMP, 802.1X ,SSL/
TLS, ARP, NTCIP, CIFS/SMB
Interface
10Base-T/100 BaseTX Ethernet (RJ-45)
*It is highly recommended to use standard
Cat. 5e & Cat. 6 cables which are
compliant with the 3P/ETL standard.
ONVIF
Supported, specication available at www.
onvif.org
Intelligent Video
Video Motion Detection Five-window video motion detection
Alarm and Event
Alarm Triggers
Motion detection, manual trigger,
periodical trigger, system boot, recording
notication, camera tampering detection,
audio detection
Alarm Events
Event notication using HTTP, SMTP, FTP, NAS
server and MicroSD Card
File upload via HTTP, SMTP, FTP, NAS server
and MicroSD card
General
Connectors RJ-45 for Network/PoE connection
LED Indicator System power and status indicator
Power Input IEEE 802.3af PoE Class 0
Power Consumption Max. 11.3 W
Dimensions
159.9 x 71.92 x 60.2 mm (Dome to rear
panel), 39.2 mm (Flat to rear panel)
Weight 492 g
Casing IP66, IK10
Safety Certications CE, LVD, FCC Class B, VCCI, C-Tick, UL
Operating Temperature
Starting Temperature:
-10°C ~ 50°C (14°F ~ 122°F)
Working Temperature:
-20°C ~ 50°C (-4°F ~ 122°F)
Humidity 90%
Warranty 24 months
System Requirements
Operating System Microsoft Windows 8/7
Web Browser Internet Explorer 10/11
Other Players
VLC: 1.1.11 or above
Quicktime: 7 or above
Included Accessories
Others
Quick installation guide, warranty card,
mounting bracket, tilt bracket, screw pack
