VIVOTEK
User's Manual - 13
4" x 2" Handy box
B
B-1
6
Move to Step 6 when
done.
Use the adapter plate to install the camera to a single gang box.
C
1.6~1.8m
3m
2m
15º
When mounting to wall, note the characteristics of the sheye lens. The
center of the lens offers the best imaging result. The center of the lens
should be oriented to cover the object of your interest; such as a person's
facial features.
