VIVOTEK
6 - User's Manual
Many copper coated aluminum (CCA) and other non-standard conductors cabling products
are masqueraded as CAT5E or CAT6 cables. Please avoid using these CCA products
especially when cascading PoE cameras. It is a must to use Ethernet cables compliant
with the 3P/ETL standard.
IMPORTANT:
Inner View
Reset button
Rubber seal for Ethernet
I/O combo
connecter
You should not use an RJ45
connector with a strain relief boot.
IR LEDs
Microphone
RJ45 LAN
port
MicroSD
card slot
Rubber seal for I/O combo
