VIVOTEK
8 - User's Manual
3. Use the base bracket as a template, and draw drill holes using a pencil. The camera is
designed to be installed to a 3-sided corner of a room.
6x
Ø 8mm
4. Drill 6 mounting holes (8mm in diameter) into the walls and ceiling. If preferred, drill a
cable routing hole.
