Vivotek FD816B-HF2 User Manual

VIVOTEK
User's Manual - 33
Buttons Conguration
Click the Congure Buttons button, a window will prompt as shown below. Please follow the steps
below to congure your joystick buttons:
1. Select a button number from the Button # pull-down menu.
2. Select a corresponding action, such as Patrol or Preset#.
If you are not sure of the locations of each
button, use the Properties window in the Game
Controllers utility.
Tips:
3. Click the Assign button to assign an action
to the button. You can delete an association
by selecting a button number, and then click
the Delete button.
Repeat the process until you are done with
the conguration of all preferred actions.
The buttons you dene should appear on the
button list accordingly.
4. Please remember to c lick the Save button
on the Client settings page to preserve your
settings.

Vivotek FD816B-HF2 Specifications

General

Brand	Vivotek
Model	FD816B-HF2
Category	Security Camera
Language	English
