Vivotek FD816BA-HT - Page 7

VIVOTEK
User's Manual - 7
77.3°
121°
5M
5M
3
3. Plan your installation by speculating on the effective range and direction of PIR sensor.
4
4. Attach the included alignment sticker to a preferred location. Drill holes for mounting
screws and if preferred, drill a routing hole. Secure
