20 - User's Manual
Installation option A:
A-1. Pass the I/O extension kit cable through the cabling hole.
CONN 2 6 pin
CONN 1 10 pin
Tabs
DI-: Yellow
DI1+: Blue
DO1-: Orange
DO+(12V): Brown
DI-: Green
DI2+: White
DO2-: Purple
DO+(12V): Gray
CONN 2 6 pin
CONN 1 10 pin
A-2. Connect the pin headers to the I/O extension module and that on the camera. Note
the orientation of the pin headers with the positions of the tabs. Properly install the
grommet as previously described.
