VIVOTEK
24 - User's Manual
9. Use the alignment sticker to drill mounting holes on a ceiling or wall. If drilling a routing
hole is not allowed, you can use the side-routing bracket to route cables through a 3/4"
conduit from the side of the camera.
A
3/4"
Ø< 35mm
≤3/4”
Note that the diameter of the hex lock nut of the conduit connector should not be larger
than 35mm.
3/4"
