Vivotek FD9391-EHTV Quick Installation Guide

1
14
# Name
1 AC 24V
2 AC 24V
3 DC 12V IN-
4 DC 12V IN+
5 N/C
6 N/C
7 DI- (Common ground for DI and DO)
8 GND
9 DI+ 0
10 GND
11 DO- 0
12 DO+ (5V; if used, can be paired with DO- 0.)
13 MIC-IN P (Connect ground to pin #8)
14 AUDIO-OUT P (Connect ground to pin #8)
- OR -
10
Ø 5 ~ 6.3mm
approx.
15cm
4 5 6
7
3/4"
Ø< 35mm
≤3/4”
8
64 GB
10
I
1
11
9

Vivotek FD9391-EHTV Specifications

General

Brand	Vivotek
Model	FD9391-EHTV
Category	Security Camera
Language	English
