14
Ø 290 mm hole
in diameter
3. For details about installing camera to the brackets, please refer to previous discussions
on page 7, page 9, page 10, page 11, and page 12; from step 3 to 7, step 10, and step
11.
4. Drill a hole on the ceiling that is 290mm in diameter.
6. Pull the stainless clamp on both sides of the housing out and into position.
5. Install the housing to the ceiling.
IP8152_housing_ig_VVTK_v1.0_20121206.indd 14 2013/1/10 下午 01:36:47
