3-7. Junciton Box Installation
1
2
3
4
Below are the package contents of the AM-711 junction box:
1. Junction box.
2. Screws for box type brackets.
3. Hex wrench.
4. Screws for speed dome type brackets or housings.
A 3/4" conduit is required for the
waterproof connector in the center, and
another 1-inch conduit should be tted to
the bottom connector.
