7.24 3D Privacy mask
Group: privacymask3d_c<0~(n-1)> for n channel products and m privacy mask window.
(capability_image_c<0~(n-1)>_privacymask_wintype = 3Drectangle)
n denotes the value of "capability_nvideoin" and m denotes the value of
"capability_videoin_c<0~(n-1)>_nprivacymask"
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable the 3D privacy mask
color 0~"
capability_image_c<0~(n-1)
>_privacymask_ncolor"
4/4 Privacy mask color
win_i<0~(m-1)>_name string[40] 4/4 Name of the privacy mask window.
win_i<0~(m-1)>_pan "capability_ptz_minpan" ~
"capability_ptz_maxpan"
4/4 Pan position of window position.
win_i<0~(m-1)>_tilt "capability_ptz_mintilt" ~
"capability_ptz_maxtilt"
4/4 Tilt position of window position.
win_i<0~(m-1)>_zoom "capability_ptz_minzoom" ~
"capability_ptz_maxzoom"
4/4 Zoom position of window position.
win_i<0~(m-1)>_fliped <boolean> 4/4 Flip side of window position.
0: Non-flip side
1: Flip side
