4. Install the camera stand to camera.
5. Connect an Ethernet cable to the camera.
TM
T6
DO+ (+5V)
DO-
DI1+
DI2+
DI3+
DI- (common ground)
RS485-
RS485+
AC/DC pw
12V or 24V, no
polarity
AC/DC pw
The DO pin can provide a 5V output, and the max. load is 50mA.
6. Install an SD card, and, if preferred, connect DI/DO wires to the terminal block The AC/
DC pins can accept either 12V or 24V power input with no polarity.
