General I/O Terminal Block
This Network Camera provides a general I/O terminal block which is used to connect external
input devices. The pin denitions are described below.
DI Diagram
Please refer to the following illustration for the connection method.
MicroSD/SDHC Card Capacity
This network camera is compliant with MicroSD/SDHC 32GB and other preceding standard SD
cards.
GND
DI
AC24V
AC24V
Pin Name
GND Ground
DI Digital Iutput
AC24V 24V
AC24V 24V
+12V
Digital input
PIN 2
Ground
PIN 1
