Physical Description
2
IR LED
Lens
Light Sensor
General I/O
Terminal Block
SD/SDHC Card Slot
Zoom Controller
Focus Controller
Reset Button
General I/O Terminal Block
Ethernet 10/100
RJ45 Plug
Power Cord Socket
+ AC 24V +
- AC 24V -
When inserting an SD/SDHC card,
note the orientation of the contacts.
