Vivotek IP8371 - Technical Specifications

VIVOTEK
User's Manual - 201
Technical Specications
Mounting Kits
Model
CPU
Flash
RAM
Image Sensor
Maximum Resolution
Lens Type
Focal Length
Aperture
Auto-iris
Field of View
Shutter Time
WDR Technology
Day/Night
Minimum Illumination
Pan/tilt/zoom Functionalities
IR Illuminators
On-board Storage
Compression
Maximum Frame Rate
Maximum Streams
S/N Ratio
Dynamic Range
Video Streaming
Image Settings
Audio Capability
Compression
Interface
Users
Protocols
Interface
ONVIF
Video Motion Detection
System Information
Camera Features
Video
Audio
Network
Intelligent Video
IP8371/IP8371E
Multimedia SoC (System-on-Chip)
256 MB
512 MB
1/2.8" Progressive CMOS
2048x1536
Vari-focal, remote focus
f = 3 ~ 9 mm
F1.2 (wide) ~ F2.3 (tele)
P-iris
36° ~ 82° (horizontal)
27° ~ 62° (vertical)
44° ~ 107° (diagonal)
1/5 sec. to 1/8,000 sec.
WDR Enhanced
Removable IR-cut filter for day & night function
Smart IR Technology to avoid overexposure
0.1 Lux @ F1.2 (Color)
0.001 Lux @ F1.2 (B/W)
ePTZ:
48x digital zoom (4x on IE plug-in, 12x built-in)
Built-in IR illuminators, effective up to 30 meters
IR LED*4, with Smart IR Technology
SD/SDHC/SDXC card slot
H.264, MJPEG & MPEG-4
H.264:
30 fps at 2048x1536
60 fps at 1920x1080
MPEG-4:
30 fps at 2048x1536
52 fps at 1920x1080
MJPEG:
30 fps at 2048x1536
60 fps at 1920x1080
4 simultaneous streams
Above 62 dB
59 dB
Adjustable resolution, quality and bitrate
Adjustable image size, quality and bit rate
Time stamp, text overlay, flip & mirror
Configurable brightness, contrast, saturation, sharpness, white
balance, exposure control, gain, backlight compensation, privacy
masks,Scheduled profile settings
3D Noise Reduction, Smart Stream
Audio input/output (full duplex)
GSM-AMR, AAC, G.711, G.726
External microphone input
External line output
Live viewing for up to 10 clients
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/RTCP,
IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS, PPPoE, CoS,
QoS, SNMP, 802.1X
10Base-T/100 BaseTX Ethernet (RJ-45)
Supported, specification available at www.onvif.org
Triple-window video motion detection
Technical Specifications
Compatible Accessories
Dimensions
AM-311
Pole Mount Adaptor
AM-411
Corner Mount Adaptor
Power Adapter
AA-231
DC 12V Power Adapter
PoE Kits
POE-IJ-1748NDN
PoE injector, 802.3af compliant
Alarm Triggers
Alarm Events
Smart Focus System
Connectors
LED Indicator
Power Input
Power Consumption
Dimensions
Weight
Casing
Safety Certifications
Operating Temperature
Warranty
Operating System
Web Browser
Other Players
CD
Others
Alarm and Event
General
System Requirements
Included Accessories
Video motion detection, manual trigger, digital input, periodical
trigger, system boot, recording notification, camera tampering
detection
Event notification using HTTP, SMTP, FTP and NAS server
File upload via HTTP, SMTP, FTP and NAS server
Remote focus & easy focus
RJ-45 cable connector for Network/PoE connection
Audio input
Audio output
AC 24V power input
DC 12V power input
Digital input*1
Digital output*1
Analog video output
System power and status indicator
DC 12V
AC 24V
IEEE 802.3af PoE Class 3
IP8371
DC: Max.12 W
AC: Max. 14.1 W
PoE: Max. 11 W
IP8371E
DC: Max.26 W (Heater on), 7.5 W (Heater off)
AC: Max. 27 W (Heater on), 7.7 W (Heater off)
PoE: Max. 11 W
Ø: 85 mm x 221 mm
Net: 1291.5 g (IP8371)
Net: 1,335 g (IP8371E)
Weather-proof IP67-rated housing
CE, LVD, FCC Class A, VCCI, C-Tick, UL
IP8371:
Starting Temperature: -10°C ~ 50°C (14°F ~ 122°F)
Working Temperature: -20°C ~ 50°C (-4°F ~ 122°F)
IP8371E:
Starting Temperature: -40°C ~ 50°C (-40°F ~ 122°F)
(PoE: -10°C ~ 50°C)
Working Temperature: -50°C ~ 50°C (-58°F ~ 122°F)
24 months
Microsoft Windows 7/Vista/XP/2000
Mozilla Firefox 7~10 (Streaming only)
Internet Explorer 7.x or 8.x
VLC: 1.1.11 or above
QuickTime: 7 or above
User's manual, quick installation guide, Installation Wizard 2, free
ST7501 32-channel VMS
Quick installation guide, warranty card, sun shield, wall mount
bracket, waterproof RJ45 Ethernet enclosure, alignment sticker,
desiccant bag, waterproof connector
All specications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved.
Ver 1.3
Distributed by:
6F, No.192, Lien-Cheng Rd., Chung-Ho,
New Taipei City, 235, Taiwan, R.O.C.
T: +886-2-82455282 F: +886-2-82455532
E: sales@vivotek.com
VIVOTEK INC. VIVOTEK USA
2050 Ringwood Avenue,
San Jose, CA 95131
T: 408-773-8686 F: 408-773-8298
E: salesusa@vivotek.com
VIVOTEK Europe
Randstad 22-133, 1316BW Almere,
The Netherlands
T: +31(0)36-5298-434
E: saleseurope@vivotek.com
97 mm 221 mm
221 mm
296 mm
91 mm
