Technical Specications
All specifications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved. Ver. 3
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C. T: +886-2-82455282 F: +886-2-82455532 E: sales@vivotek.com W: www.vivotek.com
VIVOTEK INC.
Model IP9181-H
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128MB
RAM 512MB
Camera Features
Image Sensor 1/1.8" Progressive CMOS
Maximum Resolution 2560x1920(5MP)
Lens Type Vari-Focal
Focal Length f= 4.1 ~ 9 mm
Aperture F1.6 ~ F2.4
Auto-iris DC-iris ( P-iris reserved)
Field of View
46° ~ 90° (Horizontal)
35° ~ 68° (Vertical)
58° ~ 117° (Diagonal)
ShutterTime 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Pro
Day/Night Removable IR-cutfilterfor day & night function
Mi
nimum Illumination
0.07 Lux @ F1.6 (Color)
0.001 Lux @ F1.6 (B/W)
Pan/Tilt/Zoom Functionalities
ePTZ:
48x digital zoom (4x on IE plug-in, 12x built in)
On-board Storage
Slot Type: MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
Compression H.265 & H.264 & MJPEG
Maximum Frame Rate
H.265 & H.264:
30 fps @ 2560x1920
60 fps @ 1920x1080
MJPEG:
12 fps @ 2560x1920
30 fps @ 1920x1080
Maximum Streams 4 simultaneous streams
S/N Ratio 57 dB
Dynamic Range 100 dB
Video Streaming
Adjustable resolution,qual
ity and bitrate
Smart StreamII
Image Settings
Time stamp, text overlay, flip & mirror
Configurable brightness, contrast,saturation,
sharpness, whitebalance, exposure control, gain,
backlight compensation, privacy masks
Scheduled profile settings, video rotation, 3DNR,
defog, SnapshotFocus, Lens Profile, DIS
Audio
AudioCapability Two-Way Audio (full duplex)
Compression G711, G726
Interface
External microphone input
Audiooutput
Network
Users Live viewing for up to 10 clients
P
rotocols
IPv4, IPv6, TCP/IP, HTTP, HTTPS, UPnP, RTSP/RTP/
RTCP, IGMP, SMTP, FTP, DHCP, NTP, DNS, DDNS,
PPPoE, CoS, QoS, SNMP, 802.1X,UDP, ICMP, ARP, SSL,
TLS
Interface
10 Base-T/100 Base-TX /1000 Base-T Ethernet (RJ-45)
*It is highly recommended to use standard CAT5e
& CAT6 cables which are compliant with the 3P/ETL
standard.
ONVIF
Supported, specifications available at www.onvif.
org
Intelligent Video
Technical Specifications
Video Motion Detection Five-window video motion detection
VCA*
Line crossing detection, field detection,loitering
detection
Alarm and Event
Alarm Triggers
Advancedmotion detection, manualtrigger, digital
input, periodical trigger, system boot, recording
notification, camera tampering detection,audio
detection
Alarm Events
Event notificationusing digital output, HTTP, SMTP,
FTP and NAS server, SD Card
File upload viaHTTP, SMTP, FTP, NAS server and SD
card
General
Smart Focus System Remote Back Focus via UI
Connectors
RJ-45 cable connector for 10/100/1000Mpbs
Network/PoE connection
Audioinput
Audiooutput
DC 12V power input
AC 24V Power input
Digital input*3
Digital output*1
LED Indicator System power and status indicator
Power Input
DC 12V
AC 24V
IEEE 802.3af/at PoE Class 0
Power Consumption Max. 9.7 W
Dimensions 210 (D) x 70 (W) x 63 (H) mm
Weight 766 g
Safety Certifications CE, LVD, FCC Class B, VCCI, C-Tick, UL
Operating Temperature
Starting Temperature: 0°C ~ 50°C
(32°F ~ 122°F )
Working Temperature: -10°C ~ 50°C (14°F ~ 122°F )
Humidity 90%
Warranty 36 months
System Requirements
Operating System Microsoft Windows 8/7/Vista/XP/2000
Web Browser
Mozilla Firefox 7~10(streaming only)
Internet Explorer 7/8/9/10/11
Other Players
VLC: 1.1.11 or above
Quicktime: 7 or above
Included Accessories
CD
User's manual, quick installation guide, Installation
Wizard 2,VAST
Others
Quickinstallation guide, mounting bracket, screw
pack, Lens
Dimensions
70 mm
210 mm
157 mm
63mm
Compatible Accessories
Enclosures Others
AE-237
Camera Enclosure, AC 24V,
IP66,IK10, -20°C ~ 50°C
AE-241
Camera Enclosure with
Internal IR, PoE, IP66, IK10,
-20°C ~ 50°C
AE-242
Camera Enclosure with
Internal IR, UPoE, IP66, IK10,
-40°C ~ 50°C
AI-104-010/025/035
24W IRLED, distance
100M/50M/25M, -40°C ~ 50°C,
12~24VDC or 24VAC in
* Availableper project request.
