VIVOTEK
User's Manual - 195
sizepx <0~Wx0~ H>
W: 0~ The current image width -1
H: 0~ The current image height -1
4/4 Width and height of the window.
* Only available when px is listed in
"capability_image_c<n>_exposure_windomai
n".
homestd <0~9999,0~9999> 4/4 Left-top corner coordinate of the window.
* Only available when std is listed in
"capability_image_c<n>_exposure_windomai
n".
sizestd <0~9999x0~9999> 4/4 Width and height of the window.
* Only available when std is listed in
"capability_image_c<n>_exposure_windomai
n".
Group: exposurewin_c<0~(n-1)>_profile_i<0~(m-1)> for n channel profuct and m profile,
n denotes the value of "capability_nvideoin", m denotes the value of "capability_nvideoinprofile",
(Only valid when capability_image_c<n>_exposure_mode =1)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
mode auto, custom,blc
* Available values are listed in
"capability_image_c<n>_exposu
re_winmode"
4/4 The mode indicates how to decide the
exposure.
"auto": Use full view as the only one exposure
window.
"custom": Use inclusive and exclusive
window.
"blc": Use BLC(Back Light Compensation),
and the only exposure window is located at the
center of view.
Group: exposurewin_c<0~(n-1)>_profile_i<0~(m-1)>_win_i<0~(k-1)> for m profile and n channel product,
n denotes the value of "capability_nvideoin", m denotes the value of "capability_nvideoinprofile",
k denotes the value of "capability_image_c<n>_exposure_winnum".
(Only valid when exposurewin_c<n>_mode=custom)
NAME VALUE SECURITY
(get/set)
DESCRIPTION
enable <boolean> 4/4 Enable or disable the window.
policy 0~1 4/4 0: Indicate exclusive.
1: Indicate inclusive.
