Vivotek MD8563-HF2 User Manual

VIVOTEK
User's Manual - 9
4. Attach the alignment sticker to a preferred location. Drill holes on the wall or ceiling to
install the plasic anchors. Anchors may not be necessary for installation on all materials.
If preferred, drill one routing hole.
2
1
4
DI-
DO+
DI+
DO-
VDC
Switch
BJT transistor
Relay
AC
Source
NO NC
External
device
