VIVOTEK
10 - User's Manual
0002D10766AD
XXXXXX
1. Jot down the camera's MAC address for later reference.
2. Loosen the T10 anti-tamper screws to temporarily remove the top cover.
3. If preferred, connect the digital output, digital input, or audio line-in wires.
Name
DO+ (5V, max. 50mA)
GND
DI+ (any input <30V)
DI- GND
Name
Audio Line-IN
GND
