Do not loosen these crosshead screws. They are used to secure the components.
BEND
RADIUS
HL3: min. bend radius 72mm (10x O.D.) during installation
36mm (5x O.D.) during operation
HL1: min. bend radius 67.5mm (9x O.D.) during installation
37.5mm (5x O.D.) during operation
Cable
The combo cable is made of re-retardant materials. It may be rigid when tting
it through the vehicle panel. Note the bend radius of the cable as shown below:
