VIVOTEK
20 - User's Manual
180°: bottom
top
0°:
Note that the numeric markings on the lens gimbal can be used to indicate the
degrees of rotation.
For example, if the camera is mounted on a vertical surface, and the lens is turned
90 degree to accommodate the mount position, the 90 degree marking should be
displayed at the center of the lens gimbal.
