VIVOTEK
User's Manual - 409
Technical Specications
Dimensions
Warranty 36 months
System Requirements
Operating System
Microsoft Windows 8/7
Mac 10.12 (Chrome only)
Web Browser
Chrome 58.0 or above
Internet Explorer 10/11
Other Players
VLC: 1.1.11 or above
QuickTime: 7 or above
Included Accessories
Others Quick installation guide, screwdriver, alignment sticker, desiccant bag
110. 8 mm 98 mm
54 mm
All specications are subject to change without notice. Copyright © VIVOTEK INC. All rights reserved. Ver. 2
6F, No.192, Lien-Cheng Rd., Chung-Ho, New Taipei City, 235, Taiwan, R.O.C. | T: +886-2-82455282 | F: +886-2-82455532 | E: sales@vivotek.com | W: www.vivotek.com
Technical Specications
Model
MD9560-H(2.8mm)
MD9560-H(3.6mm)
System Information
CPU Multimedia SoC (System-on-Chip)
Flash 128MB
RAM 256MB
Camera Features
Image Sensor 1/2.9" Progressive CMOS
Max. Resolution 1920x1080 (2MP)
Lens Type Fixed-focal
Focal Length
MD9560-H(2.8mm): f = 2.8 mm
MD9560-H(3.6mm): f = 3.6 mm
Aperture
MD9560-H(2.8mm): F1.8
MD9560-H(3.6mm): F2.0
Iris type Fixed-iris
Field of View
MD9560-H(2.8mm):
108° (Horizontal)
60° (Vertical)
124° (Diagonal)
MD9560-H(3.6mm):
89° (Horizontal)
47° (Vertical)
105° (Diagonal)
Shutter Time 1/5 sec. to 1/32,000 sec.
WDR Technology WDR Pro
Day/Night Yes
Removable IR-cut lter Yes
IR Illuminators Built-in IR illuminators, effective up to 20 meters with Smart IR, IR LED*2
Minimum Illumination
MD9560-H(2.8mm):
0.13 Lux @ F1.8 (Color)
0.01 Lux @ F1.8 (B/W)
0 Lux with IR illumination on
MD9560-H(3.6mm):
0.16 Lux @ F2.0 (Color)
0.01 Lux @ F2.0 (B/W)
0 Lux with IR illumination on
Pan Range ±30°
Tilt Range 90°
Rotation Range ±180°
Pan/Tilt/Zoom Functionalities ePTZ: 48x digital zoom (4x on IE plug-in, 12x built-in)
On-board Storage
Slot type: MicroSD/SDHC/SDXC card slot
Seamless Recording
Video
Compression H.265, H264, MJPEG
Maximum Frame Rate 30 fps @ 1920x1080
