Vivotek SC8131 User Guide

VIVOTEK
User Guide - 7
2.4 m ~3.6 m
+
Software config.
page
Ceiling height - camera canister height (4cm)
3. The receommended installtion position is
2.4m
~
3.6m
. Higher position is also allowed.
For positions higher than
3.6m
, you can also use the Zoom-in mode operation.
3-1. Use a spirit level to ensure the camera is installed level.
3-2. Use a laser distance meter to measure the installation height. The height
information
MUST BE
correctly measured and entered in the camera's conguration
page.
3-3. Please
delete
the height of the camera canister, e.g., 250cm (ceiling height) -4cm
(the height of camera canister) = 246cm. The reason for doing so is because the
lenses are at the lower edge of the canister.

Vivotek SC8131 Specifications

General

Built-in HDD	No
Flash memory	256 MB
Card reader integrated	Yes
Compatible memory cards	MicroSD (TransFlash), MicroSDHC, MicroSDXC
Sensor type	CMOS
Optical sensor size	1/3 \
Maximum resolution	2560 x 960 pixels
Video formats supported	H.264, M-JPEG
Power consumption	300 mA
Power source type	PoE
Power consumption (Power over Ethernet (PoE))	12.95 W
Type	IP security camera
Certification	CE, LVD, FCC B, VCCI, C-Tick, UL
Placement supported	Indoor
Connectivity technology	Wired
Interface	RJ-45
Form factor	-
Mounting type	Ceiling
Product color	White
LED indicators	Power, Status
Networking standards	IEEE 802.3af
Number of cameras	1
Operating temperature (T-T)	-10 - 40 °C
Windows operating systems supported	Windows 2000, Windows 7, Windows 8, Windows Vista, Windows XP Home, Windows XP Home x64, Windows XP Professional, Windows XP Professional x64
Intelligent Video Surveillance (IVS) system features	People counting
Minimum illumination	- lx

Weight and Dimensions

Depth	160 mm
Width	70 mm
Height	38 mm
Weight	396 g
