Vizio D24h-E1 User Manual

9
1
To mount your TV on a wall, you will need a wall mount. onsult the
information on this page to nd the appropriate mount for your TV.
e sure the mount you choose is capable of supporting the
weight of the TV. After you have determined that you have
the correct mount for your TV, you can begin the installation.
To install your TV on a wall
1. Disconnect any cables connected to your TV.
2. lace the TV face-down on a clean, at, stable surface. e sure the
surface is clear of debris that can scratch or damage the TV.
3. emove the stands by loosening and removing the screws.
4. Attach your TV and wall mount to the wall, carefully following the
instructions that came with your mount. Use only with a UL-listed wall
mount bracket rated for the weightload of this TV.
WALL-MOUNTING THE TV
D24h-E1
Screw Sie
M4 x 0.7 (P)
Hole attern  mm V x  mm H
eight wo Stand
7.28 lb
(3.30 kg)
Installing a Television on a wall requires
lifting. To prevent inury or damage to the
TV, ask someone to help you.

Vizio D24h-E1 Specifications

General

Screen Type	led
Wall Mount	100mm x 100mm
Features	edge-lit led backlight, vizio internet apps plus
Tuner	digital
Screen Size	23.54 inches, 24 inches
Refresh Rate	60hz
Closed Captioning	yes
HDR	no
Built-In Speakers	yes
Surround Sound	dts studio sound
Speakers Output	4 watts
HDMI ARC Ports	yes
USB Ports	1
USB 2.0 Ports	0
USB 3.0 Ports	0
RF Antenna	no
Bluetooth	no
Network	built-in wi-fi, ethernet
Digital Optical Audio Outputs	0
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	0
DVI	0
VGA Ports	0
SmartTV	vizio internet apps (v.i.a.)
Remote Control	standard
3D	no
Power Consumption	36 kilowatt hours
Depth with Stand	6.3 inches
Height with Stand	15 inches
Width with Stand	22 inches
Net Weight with Stand	7.5 pounds
Depth without Stand	2.4 inches
Height without Stand	13.2 inches
Net Weight without Stand	7.3 pounds
