Installing the TV on a Wall
To mount your TV on a wall, you will need a wall mount. Consult the information below to nd the
appropriate mount for your TV model:
Be sure the mount you choose is capable of supporting the weight of the TV. After you have
determined that you have the correct mount for your TV, you can begin the installation.
To install your TV on a wall:
1. Disconnect any cables connected to your TV.
2. Place the TV face-down on a clean, at, stable surface. Be sure the surface is clear of debris
that can scratch or damage the TV.
3. Remove the stands by loosening and removing
the screws.
4. Attach your TV and wall mount to the wall, carefully following the instructions that came with
your mount. Use only with a UL-listed wall mount bracket rated for the weight/load of this TV.
For some wall mounts, you may want to use cables
with right-angle connectors. This allows the TV to rest
closer to the wall.
WALL-MOUNT SCREW LOCATIONS
D40-D1 D50-D1
Screw Size: M6 M6
Hole Pattern: 200mm (V) x 200mm (H) 200mm (V) x 200mm (H)
Weight w/o
Stand:
17.20 lbs 27.56 lbs
Installing a TV on a wall requires lifting. To prevent
injury or damage to the TV, ask someone to help you.
9
