5Using the USB Media Player
Preparing Your USB Drive to Play USB Media
To play USB media, you must rst save your les onto a USB thumb
drive:
The USB thumb drive must be formatted as FAT32.
Files on the USB thumb drive must end in a supported le
extension (.mp3, .jpg, etc.).
The player is not designed to play media from external hard
drives, MP3 players, cameras, or smartphones
Playing USB Media
To play your USB media:
1. Connect your USB thumb drive to the USB port on the side of
the TV.
2. Press the V button on the remote
.
3. Use the Arrow buttons to highlight the Multimedia app in the
V.I.A. Plus Dock and press OK. (The highlighted App is in the
center of the dock.)
4. Use the Arrow buttons to highlight the USB drive from the list
and press OK.
5. Use the Arrow buttons to highlight the type of media to
display (Music, Video, or Photo) and press OK.
6. Use the Arrow buttons to highlight the le you want to display.
Press OK. Music or video les play, photos display.
You can display your photos in fullscreen. Select the
photo, press OK, then highlight Fullscreen and press
OK.
Removing the USB Drive from the TV
To safely remove your USB drive from the TV:
1. Turn o the TV.
2. Disconnect your USB thumb drive from the USB port on the
side of the TV.
Do not remove the USB thumb drive while the TV is on.
Doing so may damage the drive.
Using the USB Media Player
The USB Media Player allows you to connect a USB thumb drive to
your TV and play music, video, or photos.
Note:
The image shown here is for illustrative purposes only and may be subject to change.
The actual number of ports and their locations may vary, depending on the model.
49

Table of Contents

Other manuals for Vizio D55u-D1

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vizio D55u-D1 and is the answer not in the manual?

Vizio D55u-D1 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal54.6 \
Display brightness- cd/m²
Native aspect ratio16:9
LED backlighting typeFull-Array
Supported video modes1080p, 2160p
Contrast ratio (dynamic)5000000:1
Display refresh rates supported120 Hz
Motion interpolation technology-
Music appsPandora, Spotify
Video appsNetflix, YouTube
Lifestyle appsFacebook, Twitter
Audio decodersDTS Studio Sound
RMS rated power10 W
Number of speakers2
PC in (D-Sub)No
HDMI ports quantity5
DVI-D ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports1
Wi-Fi standardsWi-Fi 5 (802.11ac)
Number of OSD languages3
On Screen Display (OSD) languagesENG, ESP, FRE
Product colorBlack
Panel mounting interface300 x 300 mm
AC input voltage120 V
AC input frequency60 Hz
Power consumption (standby)0.5 W
Power consumption (typical)82.4 W
Package depth162 mm
Package width1357 mm
Package height821.9 mm
Package weight21000 g
Sustainability certificatesENERGY STAR
CertificationUL, cUL, FCC Class B, HDMI 1.4/2.0, Dolby Digital Plus
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)255 mm
Height (with stand)781 mm
Weight (with stand)17000 g
Depth (without stand)64.01 mm
Width (without stand)1239 mm
Height (without stand)721.1 mm
Weight (without stand)16600 g
