VIZIO (32VL and E37VL User Manual
16
www.VIZIO.com
Remote Control Buttons
POWER ( )—Press to turn the TV on from the Standby mode. Press it
again to return to the Standby mode.
CEC-Supported Buttons:
CEC needs to be set up and enabled for these buttons to work. See CEC on
page 40 for more information.
 (Record)—Press to begin recording on your CEC-supported device.
(Pause)—Press to pause playback on your CEC-supported device.
 (Play)—Press to start Playback on your CEC-supported device.
 (Stop)—Press to stop playback/recording on your CEC-supported
device.
(Previous)—Press to skip the previous track on your CEC-
supported device.
(Reverse)—Press to reverses playback on your CEC-supported
device.
(Fast Forward)—Press to fast forward playback on your CEC-
supported device.
(Next)—Press to skip to the next chapter on your CEC-supported
device.
EXIT—Press to exit from open menus.
MENU—Press to open the On-Screen Display (OSD) menu.
OK—Press this button to display the Channel List. Press to confirm
selections for On-Screen Display (OSD) menus.
Silver Diamond (represented by   in the manual instructions)—
Pressing up, down, left, or right on the points of the diamond are used to
navigate the OSD menu. They will also be used as value settings when the
slide bar is shown on the screen and option settings to turn a feature off or on.
BACK—Press to return to a previous OSD menu.
GUIDE—Press to display detailed program information when viewing a digital
TV program.
Color Buttons (Yellow, Blue, Red, & Green)—These buttons currently do
not operate any functions on your HDTV.
VOL +/- —Press to turn the volume up or down.
MEDIA – Use this button to access the USB drive to view your pictures.
MUTE—Press to turn the sound on and off.
LAST— Press to recall the previously viewed channel.
CH +/- —Press to change the channels up or down
HDMI—Press to select the HDMI input. Press repeatedly to cycle
between both HDMI inputs.
AV—Press to select the AV input.
TV—Press to select the TV input.
Number Button Pad—Press to select a channel or enter a password.
INPUT—Press to cycle through the various devices connected to your
TV (called Inputs). The inputs cycle in the following sequence: TV, AV,
Comp, HDMI-1, HDMI-2, RGB, and Media. After you have stepped
through the entire sequence, you will return to the beginning.
- (DASH)—Press to insert a dash between the main and sub-channels. For example, channel 28-2 would
be selected by the button sequence 2, 8, DASH, 2.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vizio E321VL and is the answer not in the manual?

Vizio E321VL Specifications

General IconGeneral
Response time8 ms
Display diagonal32 \
Progressive scanNo
Display brightness500 cd/m²
Display resolution1366 x 768 pixels
Display technologyLCD
Supported video modes1080i, 480i, 480p, 720p
Contrast ratio (dynamic)100000:1
Display number of colors1.073 billion colors
Supported graphics resolutions1024 x 768 (XGA), 1920 x 1080 (HD 1080), 640 x 480 (VGA), 800 x 600 (SVGA)
CertificationCSA, CSA-US, FCC Class B
HDCPYes
RF ports quantity1
SCART ports quantity0
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Sustainability certificatesENERGY STAR
Product colorBlack
Panel mounting interface200 x 200 mm
Power consumption (typical)49 W
Power consumption (PowerSave)0.37 W
RMS rated power10 W
Analog signal format systemNTSC
Digital signal format systemATSC
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)210 mm
Width (with stand)792.23 mm
Height (with stand)570.2 mm
Weight (with stand)9900 g
Depth (without stand)89.4 mm
Height (without stand)565.9 mm
Weight (without stand)9360 g
