Vizio E400-B2 User Manual

1
5
For E480-B2
1. Align the neck with the base and snap it into place.
2. Using a Phillips screwdriver, insert three (3) M4 x 10mm
screws into the holes on the bottom of the base and tighten
them to secure it to the neck.
3. Align the neck piece with the slot in the bottom of the TV
and slide it into place as shown.
4. Using a Phillips screwdriver, insert four (4) M4 x 10mm screws
into the holes on the back of the TV and tighten them to
secure the neck to the TV.
5. When you are finished, place the TV on a stable,
level surface at least four (4) inches from the floor.
To install the base:
For E400-B2
1. Align the neck with the base and snap it into place.
2. Using a Phillips screwdriver, insert three (3) M4 x 14mm
screws into the holes on the bottom of the base and tighten
them to secure it to the neck.
3. Align the neck piece with the slot in the bottom of the TV
and slide it into place as shown.
4. Using a Phillips screwdriver, insert four (4) M4 x 14mm screws
into the holes on the back of the TV and tighten them to
secure the neck to the TV.
5. When you are finished, place the TV on a stable,
level surface at least eight (8) inches from the floor.

Vizio E400-B2 Specifications

General

Brand	Vizio
Model	E400-B2
Category	LED TV
Language	English
