INSTALLING THE BASE
Using a phillips screwdriver, tighten three (3)
M4 14 mm screws into the holes as shown above.
Place the TV screen-down on a clean, flat surface. To
prevent scratches or damage to the screen, place the TV
on a soft surface, such as carpet, rug, or blanket.
Align the neck piece with the bottom of the TV and slide it
into place as shown above.
1 2
