To install the base:
1. Align the neck piece with the bottom of the TV and slide it
into place as shown.
2. Using a Phillips screwdriver, tighten three (3) M4 12mm
Phillips screws into the center of the neck piece using a
Phillips screwdriver to secure it to the TV.
3. When you are finished, place the TV on a stable,
level surface.
Installing the TV on a Wall
To mount your TV on a wall, you will need a wall mount. Consult
the information below to find the appropriate mount for your TV
model:
Installing a TV on a wall requires lifting. To prevent
injury or damage to the TV, ask someone to help you.
E420i-B0
Screw Size: M4
Hole Pattern: 200mm (V) x 200mm (H)
Weight w/o Stand: 16.0 lbs
Be sure the mount you choose is capable of supporting the
weight of the TV. After you have determined that you have the
correct mount for your TV, you can begin the installation.
To install your TV on a wall:
1. Disconnect any cables connected to your TV.
2. Place the TV face-down on a clean, flat, stable surface.
Be sure the surface is clear of debris that can scratch or
damage the TV.
3. Remove the base by loosening and removing the screws.
4. Attach your TV and wall mount to the wall, carefully following
the instructions that came with your mount.
Use only with a UL-listed wall mount bracket rated for the
weight/load of this TV.
