5
21
CHANGING THE INPUT SOURCE
External devices such as DVD players, Blu-ray Players, and video
game consoles can be connected to your TV. To use one of
these devices with your TV, you must first change the input
source using the Input menu.
To change the input source:
1. Press the INPUT button on
the remote. The Input menu is
displayed.
2. Use the Up/Down Arrow
buttons or the INPUT button
on the remote to highlight the
input you wish to view and
press OK. The selected input is
displayed.
You can change the input names that appear on the
Input menu to make your devices easy to recognize.
See
Renaming Devices on the Input Menu
on page
42 for more information.
Note: Inputs may vary by TV.
CHANGING THE SCREEN ASPECT RATIO
The TV can display images in five different modes: Normal, Stretch,
Panoramic, Wide, and Zoom. Each mode displays the picture
differently.
To change the screen aspect ratio:
1. Press the WIDE button on the
remote.
2. Use the Arrow buttons to
highlight the aspect ratio you
wish to view and press OK.
Normal preserves the content’s
original aspect ratio. Since the
4:3 aspect ratio is not large
enough to fill the TV’s screen,
black bars are added to the left
and right of the display image.
Stretch expands the display image to fill the screen.
Images may appear wider than intended. If you are
watching widescreen (1.85:1 or 2.35:1) content, black
bars will still appear on the top and bottom of the display
image. This option is only available when the TV is
displaying a 720p/1080i source.
Panoramic expands the display image to fill the screen.
Images may appear wider than intended. If you are
watching widescreen (1.85:1 or 2.35:1) content, black
bars will still appear on the top and bottom of the display
image. This option is only available when the TV is
displaying a 480i/480p source.
Wide stretches a 4:3 aspect ratio picture to the edges
of the screen. Since the picture is being stretched, the
display image may appear distorted. If the program
is already formatted for widescreen viewing (1.85:1 or
2.35:1), then black bars will appear on the top and
bottom of the display image.
Zoom expands images with black bars to fit the screen.
Panoramic
Wide
Zoom
Normal
Stretch
Wide
Zoom
Normal
Note: Aspect ratio settings may
vary by Input source.
HDMI-3
HDMI-1
HDMI-2
TV
COMP
Input Name

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Vizio E700i-B3 and is the answer not in the manual?

Vizio E700i-B3 Specifications

General IconGeneral
Screen shapeFlat
Response time- ms
Display diagonal70 \
Display brightness- cd/m²
Display technologyLED
Native aspect ratio16:9
Supported video modes1080p
Contrast ratio (dynamic)5000000:1
Display number of colors1.073 billion colors
Viewing angle, horizontal176 °
Display refresh rates supported120 Hz
Motion interpolation technology-
3DNo
Network streaming services supportedVudu
On Screen Display (OSD) languagesENG, ESP, FRE
Audio decodersDTS Studio Sound, DTS TruSurround, DTS TruVolume
RMS rated power20 W
Number of speakers2
Music appsSpotify
Video appsHulu+, Netflix, YouTube
Lifestyle appsFacebook, Twitter
USB 2.0 ports quantityUSB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity0
Number of tuners1 tuner(s)
Remote control typeXRT112
Sustainability certificatesENERGY STAR
Power consumption (standby)0.5 W
Power consumption (typical)99 W
Product colorBlack
Panel mounting interface400 x 400 mm
Package depth194.1 mm
Package width1663.95 mm
Package height1025.91 mm
Package weight36500.6 g
Weight and Dimensions IconWeight and Dimensions
Depth (with stand)249.94 mm
Width (with stand)1567.2 mm
Height (with stand)959.4 mm
Weight (with stand)30000.6 g
Depth (without stand)68.1 mm
Height (without stand)910.6 mm
Weight (without stand)26099.71 g
