Note: The images shown here are for illustrative purposes only and may be subject to change. The actual on-screen image and text may vary, depending on the model.
To turn color channels o and on:
1. From the COLOR CALIBRATION menu, use the Arrow buttons to
highlight Color Tuner, and then press OK. The Color Tuner menu
is displayed.
2. Use the Arrow buttons on the remote to highlight Red, Green, or
Blue.
3. Press the OK button to turn the color channel o or on. An X
appears over a color channel that has been turned o.
4. Use the Arrow buttons to highlight another color channel to turn
o or on. Only two color channels can be turned o at the same
time.
5. When you are nished with the color channels, press the EXIT
button.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0
To adjust the 11 Point White Balance settings:
1. From the Color Tuner menu, use the Arrow buttons to highlight
Color Tuner, and then press the Left/Right Arrow buttons
until the 11 Point White Balance menu is displayed.
2. Use the Arrow buttons on the remote to highlight the Gain and
Color values you wish to adjust. Press the OK button and use
the Left/Right Arrow buttons to adjust the value. When you
are nished, press the OK button to save the setting.
3. When you are nished, press the EXIT button.
11 Point White Balance
Gain Red Green Blue
5% 0 0 0
Adjusting the Color Tuner Settings
The Color Tuner settings allow you to adjust the HSB color and 11
point white balance, turn color channels o for testing, and display
color bar, at, and ramp test patterns.
To adjust the HSB color settings:
1. From the COLOR CALIBRATION menu, use the Arrow buttons to
highlight Color Tuner, and then press OK. The Color Tuner
menu is displayed.
2. Use the Arrow buttons on the remote to highlight the Hue,
Saturation, Brightness, Oset, or Gain of the color you wish
to adjust. Press the OK button.
3. Use the Left/Right Arrow buttons to adjust the value. When
you are nished press the OK button to save the setting.
4. When you are nished adjusting the color tuner settings, press
the EXIT button.
Color Tuner
Red Green Blue Cyan Magenta Yellow
Hue 0 0 0 0 25 -14
Saturation -1 5 -4 0 -2 0
Brightness -24 0 -22 0 0 0
Offset 0 0 0
Gain 0 0 0
The Color Tuner, 11 Point White Balance, and test patterns
allow technicians to manually calibrate the Display. Calibration
requires specialized training, an input with precisely set
colors, and a specialized light meter.
17

Vizio E75-E3 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	75 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Full-Array
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	176 °
Motion interpolation technology	Clear Action
3D	-
Battery type	AAA
Number of batteries supported	2
Dimming type	Active LED Zones® x14
Processor cores	8
High Dynamic Range (HDR) technology	High Dynamic Range (HDR) 1000
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
HDMI ports quantity	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Audio decoders	DTS, DTS Studio Sound, DTS TruSurround, DTS TruVolume
RMS rated power	10 W
Power consumption (standby)	0.5 W
Power consumption (typical)	210 W
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, ESP, FRE
Panel mounting interface	400 x 400 mm
Remote control type	XRT135
Package type	Box
Package depth	180 mm
Package width	1800 mm
Package height	1070 mm
Package weight	39100 g

Weight and Dimensions

Depth (with stand)	381 mm
Height (with stand)	1020 mm
Weight (with stand)	28600 g
Depth (without stand)	51 mm
Width (without stand)	1680 mm
Height (without stand)	970 mm
Weight (without stand)	28150 g
