Note: The images shown here are for illustrative purposes only and may be subject to change. The actual on-screen image and text may vary, depending on the model.
Deleting a Custom Picture Mode
Custom picture modes that are no longer needed can be deleted.
To delete a custom picture mode:
1. From the PICTURE MODE EDIT
menu, use the Arrow buttons
to highlight Delete Picture
Mode, and then press OK. The
DELETE PICTURE MODE window
is displayed.
2. Use the Left/Right Arrow buttons to highlight Delete and press
OK.
3. Press the EXIT button to exit the menu screens.
Resetting a Picture Mode
A preset picture mode that has been edited can be restored to the
factory default settings.
To reset a customized preset picture mode:
1. From the PICTURE MODE EDIT
menu, use the Arrow buttons
to highlight Reset Picture
Mode, and then press OK. The
RESET PICTURE MODE window is
displayed.
2. Use the Left/Right Arrow buttons to highlight Reset and press
OK.
3. Press the EXIT button to exit the menu screens.
Inputs assigned to a deleted custom picture mode
become assigned to the Calibrated picture mode.
To delete the user created Custom 1 picture mode,
select the Delete button.
Delete Cancel
Select Reset to restore Standard
picture mode to factory defaults.
Reset Cancel
16

Vizio E75-E3 Specifications

General

Screen shape	Flat
Response time	- ms
Display diagonal	75 \
Display brightness	- cd/m²
Display technology	LED
Native aspect ratio	16:9
Native refresh rate	120 Hz
LED backlighting type	Full-Array
Contrast ratio (dynamic)	5000000:1
Viewing angle, horizontal	176 °
Motion interpolation technology	Clear Action
3D	-
Battery type	AAA
Number of batteries supported	2
Dimming type	Active LED Zones® x14
Processor cores	8
High Dynamic Range (HDR) technology	High Dynamic Range (HDR) 1000
Wi-Fi standards	Wi-Fi 5 (802.11ac)
Bluetooth version	4.1
HDMI ports quantity	4
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Ethernet LAN (RJ-45) ports	1
Audio decoders	DTS, DTS Studio Sound, DTS TruSurround, DTS TruVolume
RMS rated power	10 W
Power consumption (standby)	0.5 W
Power consumption (typical)	210 W
Number of OSD languages	3
On Screen Display (OSD) languages	ENG, ESP, FRE
Panel mounting interface	400 x 400 mm
Remote control type	XRT135
Package type	Box
Package depth	180 mm
Package width	1800 mm
Package height	1070 mm
Package weight	39100 g

Weight and Dimensions

Depth (with stand)	381 mm
Height (with stand)	1020 mm
Weight (with stand)	28600 g
Depth (without stand)	51 mm
Width (without stand)	1680 mm
Height (without stand)	970 mm
Weight (without stand)	28150 g
