Vizio M55-F0 User Manual

3
To show or hide the Flat Test Pattern:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Calibration Tests, and then press the Left/Right
Arrow buttons until the FLAT TEST PATTERN menu is displayed.
Flat Test Pattern
O
2. Use the Arrow buttons on the remote to highlight O. Use the
Left/Right Arrow buttons to select the percentage brightness
for the at test pattern. Selecting a percentage immediately
shows the at pattern at that brightness.
—or—
To disable the Flat Test Pattern, use the Left/Right Arrow
buttons to highlight O.
3. When you are nished, press the Exit button.
To show or hide the Ramp Test Pattern:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Calibration Tests, and then press the Left/Right
Arrow buttons until the RAMP TEST PATTERN menu is
displayed.
2. Use the Arrow buttons on the remote to highlight O. Use the
Left/Right Arrow buttons to select the color for the ramp test
pattern. Selecting a color immediately shows that color ramp.
—or—
To hide the Ramp Test Pattern, use the Left/Right Arrow
buttons to highlight O.
3. When you are nished, press the Exit button.
Ramp Test Pattern
O
To show or hide the SMPTE Test Pattern:
1. From the Color Tuner menu, use the Arrow buttons to
highlight Calibration Tests, and then press the Left/Right
Arrow buttons until the SMPTE TEST PATTERN menu is
displayed.
SMPTE Test Pattern
O
2. Use the Arrow buttons on the remote to highlight O. Use the
Left/Right Arrow buttons to highlight On to show the SMPTE
Pattern.
—or—
To hide the SMPTE Test Pattern, use the Left/Right Arrow
buttons to highlight O.
3. When you are nished, press the Exit button.
19

Vizio M55-F0 Specifications

General

Screen Type	led
Wall Mount	200mm x 200mm
Features	dolby vision hdr, active full array plus, chromecast built-in, infinity edge tv design
Tuner	digital
Screen Size	54.5 inches, 55 inches
Motion Enhancement	clear action 360
HDR	yes
HDR Format	dolby vision, hdr 10, hybrid log-gamma (hlg)
Built-In Speakers	yes
Surround Sound	dts studio sound, dts trusurround, dts truvolume, dolby digital plus
Speakers Output	30 watts
HDMI ARC Ports	yes
USB Ports	1
Ethernet	yes
RF Antenna	yes
Network	built-in wi-fi, ethernet
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	0
DVI	0
Smart Applications	amazon alexa, google assistant
Voice Assistant	no
Remote Control	standard
3D	no
Power Consumption	305 kilowatt hours
Depth with Stand	9.3 inches
Height with Stand	30.3 inches
Width with Stand	48.5 inches
Net Weight with Stand	35.7 pounds
Depth without Stand	2.4 inches
Height without Stand	27.9 inches
Net Weight without Stand	35 pounds
