Vizio M70-C3 User Manual

1
Installing the TV on a Wall
To mount your TV on a wall, you will need a wall mount. Consult the information below to nd the appropriate mount
for your TV model:
Be sure the mount you choose is capable of supporting the weight of the TV. After you have
determined that you have the correct mount for your TV, you can begin the installation.
To install your TV on a wall:
1. Disconnect any cables connected to your TV.
2. Place the TV face-down on a clean, at, stable surface. Be sure the surface is clear of debris that can scratch or damage the
TV.
3. Remove the base and neck by loosening and removing
the screws.
4. Attach your TV and wall mount to the wall, carefully following the instructions that came with your mount.
Use only with a UL-listed wall mount bracket rated for the weight/load of this TV.
For some wall mounts, you may want to use cables
with right-angle connectors. This allows the TV to rest
closer to the wall.
WALL-MOUNT SCREW LOCATIONS
Installing a TV on a wall requires lifting. To prevent
injury or damage to the TV, ask someone to help you.
M60-C3 M70-C3 M80-C3
Screw Size: M6 (not included) M6 (not included) M6 (not included)
Hole Pattern:
400mm (V) x
400mm (H)
400mm (V) x
400mm (H)
600mm (V) x
400mm (H)
Weight w/o Stand: 49.89 lbs (22.63 kg) 62.17 lbs (28.20 kg) 99.03 lbs (44.92 kg)
9

Vizio M70-C3 Specifications

General

Screen Type	led
Wall Mount	400mm x 400mm
Tuner	digital
Screen Size	69.5 inches, 70 inches
Refresh Rate	240hz
HDR	no
Number Of Speakers	2
USB Ports	1
RF Antenna	yes
Network	built-in wi-fi
Digital Optical Audio Outputs	1
Analog Audio Outputs	1
Component Video Inputs	1
Composite Video Inputs	1
DVI	0
SmartTV	vizio internet apps (v.i.a.)
Remote Control	smart
3D	no
Power Consumption	184 kilowatt hours
Depth with Stand	11.2 inches
Height with Stand	38.2 inches
Width with Stand	61.6 inches
Net Weight with Stand	63.23 pounds
Depth without Stand	2.7 inches
Height without Stand	35.5 inches
Net Weight without Stand	62.17 pounds
