CONFIDENTIAL
Ω
DO NOT COPYʳ Page ˅ˀ2
File No. SG-0205
6.Speaker
Output 10W (max) X2
7. ENVIRONMENT
5-1. Operating Temperature: 5c~35c (Ambient)
5-2. Operating Humidity: Ta= 35 ¶C, 90%RH (Non-condensing)
5-3. Operating Altitude: 0 - 14,000 feet (4267.2m)(Non-Operating)
8. DIMENSIONS (Physical dimension)
Width: 800 mm.
+/- 20 mm
Depth: 1060 mm +/- 20 mm
Height: 360 mm +/- 20 mm
9. WEIGHT (Physical weight)
a. Net: 19.1+/-0.5kgs
b. Gross: 24.6+/-0.5kgsn
9-1. MOUNTING PRECAUTIONS
(1) You must mount a module using holes arranged in four corners or four sides.
(2) You should consider the mounting structure so that uneven force (ex. Twisted
stress) is not applied to the module. And the case on which a module is mounted
should have sufficient strength so that external force is not transmitted directly to
the module.
(3) Please attach the surface transparent protective plate to the surface in order to
protect the polarizer.
Transparent protective plate should have sufficient strength in order to the resist
external force.
(4) You should adopt radiation structure to satisfy the temperature specification.
(5) Acetic acid type and chlorine type materials for the cover case are not desirable
because the former generates corrosive gas of attacking the polarizer at high
temperature and the latter causes circuit break by electro-chemical reaction.
(6) Do not touch, push or rub the exposed polarizes with glass, tweezers or anything
harder than HB pencil lead. And please do not rub with dust clothes with chemical
treatment.
Do not touch the surface of polarizer for bare hand or greasy cloth.(Some
cosmetics are detrimental to the polarizer.)
To Next Page
