VMAX R40 - Parts Description

1
2
5
6
7
8
9
10
11
12
13
15
16
17
18
19
14
4
20
21
3
13
R40 User manual
1. Handles
2. Accelerator
3. Display
4. Switch
5. Brake lever (left and right)
6. Handlebar
7. Folding mechanism
8. Front wheel
9. Rear wheel (motor)
10. Front light
11. Brake light
12. Side LED
13. Rear fender
14. Front swingarm
15. Rear shock absorber
16. Disc brake front
17. Disc brake rear
18. Footboard
19. Foot support
20. Stand
21. Charging port
PARTS DESCRIPTION
