Vodafone DSL - Fixed Telephony & Internet Setup

Installation steps to activate
the combined fixed telephony
and Internet access service
Disconnect the landline cable from the telephone
socket on the wall. Insert the grey DSL/LINE
telephone cable into the grey DSL port of the
Vodafone DSL Router. Insert the other end of the
cable into the telephone socket on the wall.
If you have purchased the relevant service,
connect your two telephone sets to the first and
second black PHONE ports of the Vodafone DSL
Router.
If you want to set up a wired connection to your
computer (laptop or PC), insert one end of the
yellow LAN/Ethernet cable into one of the
corresponding (yellow) ports on the back of
the Vodafone DSL Router. Insert the other end
of the cable into the Ethernet/LAN port of your
computer.
Insert the power adapter into a power socket and
the other end of the cable into the appropriate
port on the back of the device.
1
2
3
4
Telephone socket
Telephone set
Telephone set
Computer (PC/laptop)
Power socket
Vodafone DSL Router
Wi-Fi button:
Press to activate/deactivate Wi-Fi
1
2
3
4
2
