Nexus 6 User Guide V1.1
Page 8
4.4 Nexus 6 specifications
Frequency response 78 Hz - 21 kHz ±3 dB
Eciency
1
LF: 105 dB 1W/1m, HF: 110 dB 1W/1m
Crossover point 1.6 kHz active
Nominal impedance LF: 2 x 5.3 Ω, HF: 2 x 4 Ω
Power handling
2
LF: 2 x 1350 W AES, HF: 2 x 160 W AES
Maximum output
3
137 dB cont, 140 dB peak
Driver configuration 12 x 6.5” LF, 8 x 1” HF compression driver
Dispersion 110°H x 50°V
Connectors 1 x 8-pole speakON™ NL8
Height 1267 mm (49.8”)
Width 562 mm (22.1”)
Depth 430 mm (16.9”)
Weight 75.5 kg (166.5 lbs)
Enclosure Fibreglass composite
Rigging Stack mounted or proprietary suspension system
Finish Smooth cellulose
1
Measured in half space
2
AES2 - 1984 compliant
3
Calculated
Figure 4.1: Horizontal directivity isobars Figure 4.2: Vertical directivity isobars
