VOKERA Compact - Page 38

36
Compact
27
28
351
30
27
353
26
3
2
7
288
288
288
300
303
289
289
22
289
303
289
31
289
290
23
201
299
285
36
25
201
353
63
24
POS. DESCRIPTION 24 28
2 Connection 10022658 10022658
3 Pressure switch 2044 2044
7 By-pass valve 2047 2047
22 Safety valve 1806 1806
23 Connection 10022499 10022499
24 Flow governor 8009 8009
25 Pipe 10020714 10023950
26 DHW actuator 10022349 10022349
27 Heating cock 1789 1789
28 Connection 1790 1790
30 Water supplu stop cock 7099 7099
31 Venting plugs kit 01005137 01005137
36 Pipe 10020612 10023949
63 Pipe 10020898 10020898
201 Washer 5026 5026
285 NTC sensor 8484 8484
288 O ring 6898 6898
289 Clip 2223 2223
290 Clip 2165 2165
299 Washer 10022726 10022726
300 Clip 2222 2222
303 Connection 2217 2217
351 Brass nut 1823 1823
353 Ogive 1824 1824
