01-22
Test requirements
The tires installed to all wheels must be of
the same (approved) size; tires inflated to
prescribed pressure.
Mechanical/hydraulic parts of the brake
system including brake light switch and
brake lights OK.
Hydraulic lines and connections not leaking
(visual check of hydraulic unit, brake
calipers, wheel cylinders, tandem master
brake cylinder).
Wheel bearings and wheel bearing play
OK.
ABS control module (w/EDL) -J104- is
correctly bolted to hydraulic unit -N55-.
Connector on ABS control module (w/EDL)
-J104- correctly plugged-in (retainer is
engaged).
Check contacts of ABS components for
damage and correct seating.
All fuses OK according to wiring diagram
(remove fuse from fuse holder to check).
Supply voltage OK (at least 10.0 V).
