01-58
ABS control module, coding
All functions which could previously be
performed with V.A.G 1551 can also be
performed with the tester VAS 5051.
Warning light for ABS -K47- and warning light
for brake system -K118- flash when control
module is coded with 00000. An entry is not set
in the DTC memory.
The ABS control module (w/EDL) -J104- must
be recoded if the vehicle relevant coding is not
displayed or the control module has been
replaced.
Coding is only possible after the workshop code
(WSC) has been entered into the V.A.G 1551
Scan Tool.
Test sequence
- Connect V.A.G 1551 Scan Tool and select
(address word 03) "Brake electronics" with
ignition switched on; Page 01-23
- Establish which type of ABS hydraulic control
module is installed Page 01-4 .
- Establish engine code.
