9 Connecting air conditioner service
station
9.1 For vehicles that have connections on
both low-pressure and high-pressure
sides of refrigerant circuit
9.1.1 Connecting air conditioner service sta‐
tion for measuring and checking
– Switch off ignition.
– Connect air conditioner service station to power supply.
– Connect quick-release coupling adapters to charging hoses
for air conditioner service station (handwheels not turned in‐
wards, i.e. hand shut-off valves not open).
– Switch on air conditioner service station and evacuate charg‐
ing hoses (necessary only if there is air in the charging hoses).
– Switch off air conditioner service station.
– Unscrew sealing caps from service connections (with valve).
– Connect air conditioner service station via service connections
to the vehicle refrigerant circuit using quick-release coupling
adapter.
– Turn handwheel of quick-release coupling adapter inwards
only far enough to ensure that valves on service connections
are open (check using a pressure gauge; do not overstress
valves).
– Perform the intended measuring and checking work.
Amarok 2011 ➤ , Beetle 2012 ➤ , Bora 1999 ➤ , CC 2010 ➤ , CC 2012 ➤ , ...
Air conditioning system with refrigerant R134a - Edition 10.2014
126 Rep. gr.00 - Technical data
