4.2 Measure Battery Voltage
Hereinafter the measurement of the HV-Battery voltage on an e-UP! is
described.
The procedure on an eGolf is very similar. Differences will be described
separately.
1. Start the software by selcting: …│DiTEST│DSS DSS.
Note: The link is located in the Start menu under "Programs".
2. Click on Diagnostic│Charge capacitor.
Fig. 4-2 DSS Manager
3. Click on e-Up – Measure battery voltage. Click on e-Up - measure battery
voltage BL3 to measure a BL3 battery.
Fig. 4-3 Measure e-Up – Battery voltage
